Product

EMC5050

Product Features
● High brightness, small volume, pure color and large luminance Angle;
● The products are sealed with imported silica gel, with strong uv resistance and high temperature resistance, and can be used in various harsh indoor and outdoor environments for a long time;
● High power, high cost performance;
● Products can be customized in accordance with customer drive requirements, which can effectively save customers' power cost.
Applications
High shed light, street light, spotlight, bulb light, PAR light, down light and other architectural landscape lighting and general lighting field.20180411093016_88261.png

EMC5050 5W 24V
Part NumberPower (W)Luminous
Flux(lm)
VF (V) If (mA)RaCCT (K)Specification
E50501-W27SN3N5FK4M0-XXXX5550-70024-27200802700
E50501-W29SN3N5FK4M0-XXXX5550-70024-27200803000
E50501-W41SN4N6FK4M0-XXXX5600-75024-27200804000
E50501-W50SN4N6FK4M0-XXXX5600-75024-27200805000
E50501-W64SN4N6FK4M0-XXXX5600-75024-27200806500
EMC5050 5W 9V
Part NumberPower (W)Luminous
Flux(lm)
VF (V) If (mA)RaCCT (K)Specification
E50501-W27SN3N5FE9F8-XXXX5550-7009-11500802700
E50501-W29SN3N5FE9F8-XXXX5550-7009-11500803000
E50501-W41SN3N6FE8G3-XXXX5550-7509-11500804000
E50501-W50SN3N6FE9F8-XXXX5550-7509-11500805000
E50501-W64SN3N6FE8G3-XXXX5550-7509-11500806500
EMC5050 3W 9V
Part NumberPower (W)Luminous
Flux(lm)
VF (V) If (mA)RaCCT (K)Specification
E50501-W27SM0N0FE9F4-XXXX3300-4509-11300802700
E50501-W29SM0N0FE9F4-XXXX3300-4509-11300803000
E50501-W41SM2N1FE9F4-XXXX3350-5009-11300804000
E50501-W50SM2N1FE9F4-XXXX3350-5009-11300805000
E50501-W64SM2N1FE9F4-XXXX3350-5009-11300806500


Product Features
● High brightness, small volume, pure color and large luminance Angle;
● The products are sealed with imported silica gel, with strong uv resistance and high temperature resistance, and can be used in various harsh indoor and outdoor environments for a long time;
● High power, high cost performance;
● Products can be customized in accordance with customer drive requirements, which can effectively save customers' power cost.
Applications
High shed light, street light, spotlight, bulb light, PAR light, down light and other architectural landscape lighting and general lighting field.20180411093016_88261.png
